The LHR3010 is a 10V output, low noise, and extremely low temperature drift voltage reference with high precision. It supports both current injection and current sinking, and features excellent power supply and load regulation performance. With its unique design technology, the LHR3010 achieves an outstanding temperature stability of 3ppm/°C and high precision of 0.05%. These features combined with extremely low noise make the LHR3010 series an ideal choice for high-precision data acquisition systems.
The voltage reference is available in two grades: high-grade and standard grade.
Product Features:
- Low Temperature Drift:
- High-grade: 3ppm/°C (max)
- Standard grade: 8ppm/°C (max)
- High Precision:
- High-grade: 0.05% (max)
- Standard grade: 0.1% (max)
- Low Noise: 1.5μVpp/V
- Excellent Long-Term Stability:
- Typical value: 50ppm/1000 hours (SOP8L) for the first 1000 hours
- Typical value: 25ppm/1000 hours (SOP8L) for the next 2000 hours
- High Output Current: up to 10mA
- Temperature Range: -40°C to 125°C
Test Data:
Product Applications:
- High-precision data acquisition systems
- Engineering process control
- Pressure and temperature transmitters
- Test equipment
- Medical devices
- Laboratory and field instruments
